RADIO HELIUM RACE FRAME - METALLIC MINT
RADIO HELIUM RACE FRAME - METALLIC MINT
PRO L 20.9TT
Full Tilt Bike Co Isanti
101 Isanti Parkway Northwest
Isanti MN 55040
United States
FULL TILT BIKE CO trailer
5001 Killingsworth Lane
Pflugerville TX 78660
United States
WAREHOUSE
3909 County Road 115
Saint Augusta MN 56301
United States
Designed in conjunction with a BMX race knowledge spanning 3 decades, Radio Raceline Helium frames are powerful pure bred race machines. You'll find no gimmicks, no "goofy" tubing shapes or unnecessary features. These frames are built from the ground up with race-proven geometry and technology combined with clean, functional aesthetics to give you the holeshot out of the gate. Radio Raceline Helium frames are designed to feel comfortable, stiff, and fast, exactly how a race bike should.
GEOMETRY & SPECS
- Material: Hydroformed 6061 alloy
- Top Tube Length: 20.9 (L) 21.5 (XL) 21.75 (XXL)
- Chain Stay Length: 13.9” (L) 14.5” (XL) 14.8 (XXL)
- Dropout Size: 20mm (10, 15, & 20mm Adapters included)
- Head Tube Angle: 74º
- Seat Tube Angle: 71º
- Head Tube Size: 1 1/8” - 1.5” Tapered
- Seat Post Size: 27.2mm
- Seat Tube Length: 231mm
- Bottom Bracket Height: EU, 11.6”
- Wheel Size: 20 X 1.75
- Extra: Forged and CNC machined dropouts with integrated chain Tensioners
- Disc brake compatible
- Weight: 3.58lbs (L)/ 3.76lbs (XL)/ 3.82lbs (XXL)
